Techinical Specification :
| SR.NO. | DESCRIPTION | MATERIAL | QTY |
|---|---|---|---|
| 1 | BODY | CF8 / CF8M / WCB | 1 |
| 2 | CONNECTOR | CF8 / CF8M / WCB | 1 |
| 3 | BALL | SS + TUGSTEN CARBIDE COATED | 1* |
| 4 | SEAT | SS + TUGSTEN CARBIDE COATED | 2* |
| 5 | SEAT PUSHER | SS304/SS316/SS 410 | 2 |
| 6 | SEAT BACK RING | GRAFOIL | 2 |
| 7 | BODY GASKET | GRAFOIL | 4 |
| 8 | STEM | SS304/SS316 | 1 |
| 9 | BELLEVILLE WASHER | INCONEL-625 | 12 |
| 10 | STEM PACKING | GRAFOIL | REQ. |
| 11 | GLAND BUSH | SS316 | 1 |
| 12 | SPRING WASHER | STD | REQ. |
| 13 | STUD | STD | REQ. |
| 14 | NUT | STD | REQ. |
| 15 | HANDLE | M.S. + ZINC PLATED / SS | 1 |
| 16 | HANDLE NUT | M.S. + ZINC PLATED / SS | 2 |
| 17 | HANDLE STTOPER | M.S. + ZINC PLATED / SS | 1 |
| 18 | BELLEVILLE WASHER | SPRING STEEL | 2 |
| 19 | SLEEVE | RUBBER | 1 |
| 20 | ANTISTATIC BALL | SS | 2 |
| 21 | ANTISTATIC SPRING | SS | 2 |
