Techinical Specification :
| SR.NO. | DESCRIPTION | MATERIAL | QTY |
|---|---|---|---|
| 1 | BODY | CF8 / CF8M / WCB | 1 |
| 2 | F.E. CONNECTOR | CF8 / CF8M / WCB | 1 |
| 3 | BALL | CF8 / CF8M / WCB | 1 |
| 4 | BODY SEAL | GRAFOIL | 1 |
| 5 | BALL SEAT | PTFE / RPTFE / PEEK | 2 |
| 6 | STEM | SS304 / SS316 | 1 |
| 7 | STEM SEAL | GRAFOIL | REQ. |
| 8 | GLAND | SS304 / SS316 | 1 |
| 9 | STEM NUT | M.S. + ZINC PLATED / SS | 1 |
| 10 | DISC WASHER | SPRING STEEL | 2 |
| 11 | HANDLE | M.S. + ZINC PLATED / SS | 1 |
| 12 | HANDLE NUT | M.S. + ZINC PLATED / SS | 1 |
| 13 | SLEEVE | RUBBER | 1 |
| 14 | ANTISTATIC BALL | S.S. | 2 |
| 15 | ANTISTATIC SPRING | S.S. | 2 |
| 16 | STUD | STD | REQ. |
| 17 | NUT + WASHER | STD | REQ. |
| 18 | O-RING | VITON / NBR | 1 |
| 19 | HANDLE STOPPER | M.S. + ZINC PLATED / SS | 1 |
| 20 | LOCKING | M.S. + ZINC PLATED / SS | 1 |
